The NEWTOP D60 Diesel Outboard Motor is developed for operators requiring higher torque, extended running capability, and diesel-powered efficiency. Featuring a turbocharged 1,390cc three-cylinder engine with direct fuel injection, this 60HP model provides dependable propulsion for rescue craft, workboats, patrol vessels, and demanding transport applications.
Unlike smaller gasoline-powered outboards that prioritize portability, the D60 is developed around sustained output and heavy-duty working capability. Its turbocharged diesel engine delivers strong low-end torque and dependable pulling power, making it suitable for larger vessels and operations where carrying capacity is a priority.
The direct-injection fuel system supports efficient combustion and stable performance, while electric starting helps simplify deployment. Operators can choose between tiller-handle and remote-control steering arrangements according to vessel configuration and operational requirements.
To accommodate different load profiles and working conditions, the D60 supports multiple propeller options and features electric trim and tilt adjustment. Together with its diesel power platform, these features help create an outboard motor focused on endurance, controllability, and long-term operational efficiency.
| Leistungstyp | Diesel |
| Max. Ausgangsleistung | 60hp/45kW |
| Tansomhöhe | 590mm |
| Motortyp | L3 Cylinder,4-Schlaganfall,Water-cooled,supercharged,Diesel Engine |
| Verschiebung | 1390cc |
| Bore X Stroke | 80X92mm |
| Kraftstoffansaugsystem | Direct-injection |
| Lenksystem | Tiller/Remote |
| Startsystem | Elektrisch |
| Schalthebel | F-N-R |
| Übersetzungsverhältnis | 1.786 |
| Trimmen und Neigen | Elektrisch |
| Max. Kraftstoffverbrauch | 12L/h |
| Lubrication System | API:Grade CF-4 Engine Oil and Above |
| Lubrication Oil Capacity | 3.5~4L |
| Rectifier Charging Capacity | 12V |
| Propelleroptionen | 3-13"/15"/17" |
| N. W. /G. W. | 260kgs |
